Weighing and packing machine

Short Description:

1, bulk noodle packing machine: one set,

2, conveyor line: one set,

3, weighting machine: three set,

4,lifting engine (elevator):three set,

Send email to us

Product Detail

Product Tags

Stick Noodle Feeding System (1)

Introduction

·Contains: 1, bulk noodle packing machine: one set,
2, conveyor line: one set,
3, weighting machine: three set,
4,lifting engine (elevator):three set,
Application : automatically finish the process of weighting, outputting, filling and sealed packing of the Spaghetti and noodle

Object：	noodle, Spaghetti
length of the noodle	200g～500g：（180～260mm）±5.0mm；500g～1000g：（240～260mm）±5.0mm
thickness of the noodle	0.6～1.4mm
width of the noodle	0.8～3.0mm
packing rate	30-60/min
weight range	200～500g 200～1000g
exact value for 1-1.7mm spaghetti	200～500g ，±2.0g-96%； 500～1000g，±3.0g-96%；
Dimensions	6700mm×3400mm×1650mm
voltage	AC220v/50-60HZ/5800W

Highlights

HICOCA’s patented product, with the help of the servomotor, the packing procedure is very smooth and stable. And the packed products are neat.
Reduce the labor cost by decrease the labour intensity. The capacity of one line is around 30mt-48mt per day, only required one person for monitoring.
The numbers of scales can be adjusted according to customer’s requirement.
