Weighing and packing machine
Introduction
·Contains: 1, bulk noodle packing machine: one set,
2, conveyor line: one set,
3, weighting machine: three set,
4,lifting engine (elevator):three set,
Application : automatically finish the process of weighting, outputting, filling and sealed packing of the Spaghetti and noodle
| Object： | noodle, Spaghetti |
| length of the noodle | 200g～500g：（180～260mm）±5.0mm；500g～1000g：（240～260mm）±5.0mm |
| thickness of the noodle | 0.6～1.4mm |
| width of the noodle | 0.8～3.0mm |
| packing rate | 30-60/min |
| weight range | 200～500g 200～1000g |
| exact value
for 1-1.7mm spaghetti |
200～500g ，±2.0g-96%；
500～1000g，±3.0g-96%； |
| Dimensions | 6700mm×3400mm×1650mm |
| voltage | AC220v/50-60HZ/5800W |
Highlights
HICOCA’s patented product, with the help of the servomotor, the packing procedure is very smooth and stable. And the packed products are neat.
Reduce the labor cost by decrease the labour intensity. The capacity of one line is around 30mt-48mt per day, only required one person for monitoring.
The numbers of scales can be adjusted according to customer’s requirement.
